We offer high quality Aerodynamics Laboratory Trainers for study of basic as well as advanced principles of Aerodynamic Engineering.
Our product range include Modular Air Flow Bench for study of basic principles of Aerodynamics & Subsonic Wind Tunnel for analysis of advanced principles of Aerodynamics. Wide range of experimental modules are available for determination of Drag & Lift Force, Pressure Distribution on Aerofoils, Boundry Layer Analysis, Flow Visualization etc.
Subsonic Wind Tunnel
The setup is an open wind tunnel used to demonstrate and measure the aerodynamic properties of various models. For this purpose, air is drawn in from the environment and accelerated. The air flows around a model, such as an aerofoil, in a measuring section. The air is then decelerated in a diffuser and pumped back into the open by a fan. The carefully designed intake nozzle and a flow straightener ensure a uniform velocity distribution with little turbulence in the closed measuring section. The test section is square in shape & made of transparent plexiglass for students to visualize the process.
Modular Air Flow Bench
Modular Air Flow bench is designed to demonstrate the behavior of bodies during flow around or through bodies with a compressible fluid. The purpose of experiments is familiarisation with and optimisation of drag and the flow field around a body. The trainer consists of a centrifugal fan, which can be used to generate flow velocities up to 40m/s. The fan speed can be changed using Variable Frequency Drive (VFD). A stabilization tank with flow straightener ensures a consistent, low-turbulence and reproducible flow in the measurement section. A carefully shaped nozzle provides a largely homogeneous velocity distribution of the air flow.
